溝切 | シーダーテープ播種機テープシーダー

Seeder machine SMV-1J

【Feature】・High-efficiency seeder machine improved so that everyone could make more precise seeder tape in less labor than before one. ・Work efficiency has been improved by changing the distance adjustment and winding length settings to numerical input methods using a touch panel. The tape speed and seed feed speed ratio are controlled synchronously, so there is no misalignment between plants due to rotational fluctuations during operation. ・The touch panel message display function improves visibility and work efficiency. Automatically stops when winding is complete, thread breaks, seeds are insufficient, or tape is insufficient, and a message is displayed with the contents. ・The vacuum pump is fixed to the pump box frame for increased safety. Additionally, the inside of the vacuum pump is treated with anti-corrosion treatment to reduce the occurrence of rust.
Model	SMV-1J
Seed Lack Sensor for SMV-1J	Vacuum Drum
Width/Depth/Height	65×57×146cm
Weight	Machine 50kg Cubicle 60kg
Range of Temperture	0～+40℃
Power Supply	AC100V (single-phase)
Electricity Consumption	Machine 4A Cubicle 7A
Working Speed	Up to 2000m／h
Adjustment	Changing a specific stainless belt, any interval and any number of seeds are available.

※ Application is based on a typical seed size. Irregular size of seeds might make it unavailable.

TSA-7

Hand-Pushing Tape Seeder TSA-7

【Feature】・Light weight and compact popular model ・For all vegetables（radish, burdock, carrot, spinach, etc.）
Model	TSA-7
Number of Lane	1
Wheel Width	100mm
Marker	Available（option）
Pesticide Spreader	Available（option）

YRJ-8030
(Continuous Fiber Bundle)

Aplicable Machine	SMV-1J
Name	YRJ-8030
Material	Rayon
Specification	8000m／roll
Number/Ctn	30rolls (=240,000m)

YJ-5048(Twisted Yarn)

Aplicable Machine	SMV-1J
Name	YJ-5048
Material	Cotton
Specification	5000m／roll
Number/Ctn	48rolls (=240,000m)

Plastic Reel

Symbol	LP
Disk	ABS Resin (recycled)
Core	ABS Resin (recycled)
Number/Ctn	50 reels

Paper Reel(S)

Symbol	PPS
Disk	Paper
Core	ABS Resin (recycled)
Number/Ctn	100 reels

Water-Resistant
Paper Reel

Symbol	OP(L)
Disk	Water Resistant Paper
Core	ABS Resin (recycled)
Number/Ctn	100 reels

Paper Reel

Symbol	PP(L)
Disk	Paper
Core	ABS Resin (recycled)
Number/Ctn	100 reels

Flat Seeder Tape

・We provide this as preorderd products for promotional giveaways.

Tape Seeder for Kitchen Garden

・Tape Seeder for Kitchen Garden

・Lightweight 1-wheel type which you are easy-to-use.

Seeder Tape for Kitchen Garden

・Subdivided Seeder Tape for Kitchen Garden

・We can provide any specification (interval & number of seeds) of Seeder Tape. Please feel free to ask us.

TK-12

Type	TK-12
Number of Lane	2
Hopper Capacity	1.6L
Applicable Pesticide	Granule
Others	Including a mechanism which adjust the rate of spreading.
Application	TSB-7,TSB-8ST,TRB-8ST,TEM-4WD2,etc.

TK-1

Type	TK-1
Number of Lane	1
Hopper Capacity	1.6L
Applicable Pesticide	Granule
Others	Including a mechanism which adjust the rate of spreading.
Application	TSA-7,TSA-8ST,TRA-8ST,etc.

Seed Belt for SMV-1J

【Feature】
・Seed Belt for SMV-1J
・We could provide the most suitable seed belt according to kind of seeds, interval and number of seeds. Please feel free to ask us.

Seeder Tape

Applicable Seeds
Roots	Daikon (Radish), Burdock, Carrot, Onion, Welsh Onion, Turnip
Leaves	Spinach, Cabbage, Chinese Cabbage, Lettuce, Broccoli, Cauliflower and other Brassica Leaves
Fruits	Water Melon, Melon, Tomato, Cucumber, Eggplant, Paprika
Others	Flower, Corn, Propagule, Rice, Bean, Herb, etc.

TRA-8ST

Precise Tape Seeder for Tractor TRA-8ST

【Feature】・Suitable for crops aquires precise shallow sowing depth（carot, stock, etc)
Model	TRA-8ST
Application	For Tractor
Number of Lanes	1
Wheel Width	100mm
Minimum Lane Width	220mm
Pesticide Spreader	Available（option）

TRA-7

Tape Seeder for Tractor TRA-7X

Model	TRA-7X
Application	For Tractor
Number of Width	2～5
Minimum Lane Width	320mm
Pesticide Spreader	Available（option）

TSJ-7BT

Electric Tape Seeder TSJ-7BT

【Feature】・Electric self-propelled model loaded with battery ・12 lanes sown at once ・Without exhaust gas, suitable for greenhouse works, also silent and safe ※Battery is not included.
Model	TSJ-7BT
Number of Lane	2～12
Wheel Width	400mm
Minimum Lane Width	30mm
Adaptable Battery	12V
Speed	1Km/h

TSD-7

Hand-Pushing Tape Seeder TSD-7

【Feature】・Most suitable for multi-lanes sowing of turnip or spinach ・Up to ４ lanes sown at once
Model	TSD-7
Number of Lanes	4
Wheel Width	500mm
Minimum Lane Width	100mm

TSB-7

Hand-Pushing Tape Seeder TSB-7

【Feature】・Light weight and friendly 2 lanes model ・Because of lightness, also suitable for 1 lane use ・For all vegetables（radish, burdock, carrot, spinach, etc.）
Model	TSB-7
Number of Lane	2
Wheel Width	200mm
Range of Lane Width	120-170mm
Marker	Available（option）
Pesticide Spreader	Available（option）

TSA-8ST

Hand-Pushing Precise Tape Seeder TSA-8ST

【Feature】・Suitable for crops aquires precise shallow sowing depth（carot, stock, etc)
Model	TSA-8ST
Number of Lane	1
Wheel Width	100mm
Marker	Available（option）
Pesticide Spreader	Available（option）

	外径	覆土板	適用作物
D-8	8mm	有	ニンジン（生種子）、かぶ、小松菜、カンラン、ブロッコリー、水菜、白菜
PD-8	8mm	無	ニンジン（生種子）、かぶ、小松菜、カンラン、ブロッコリー、水菜、白菜
A-10	10mm	有	大根、ごぼう、ほうれん草、ニンジン（コート種子）、葱、玉葱
P-10	10mm	無	大根、ごぼう、ほうれん草、ニンジン（コート種子）、葱、玉葱
A-13	13mm	有	大根（コート種子）、ひまわり
P-13	13mm	無	大根（コート種子）、ひまわり
A-16	16mm	有	スイートコーン、大豆
P-16	16mm	無	スイートコーン、大豆
P-19	19mm	無	落花生
P-25	25mm	無	むかご

安心・確実な播種方法、シーダー農法は日本プラントシーダー
